That is a creative reuse of a water purifier booster pump! Since those are permanent magnet DC (PMDC) motors, they work quite well as small-scale wind generators.
Because wind speed is inherently unpredictable, the voltage your dynamo generates will fluctuate constantly based on how fast the blades spin. To get a stable, constant 12V DC output, you need to regulate the voltage.
Here is the setup you need to get a stable 12V DC output:
1. The Core Solution: An Automatic Buck-Boost DC-to-DC Converter
Since your pump is rated for 24V, it might produce anywhere from 2V (low wind) to over 24V (high wind). A standard step-down regulator won't work when the wind drops.
What to use: Look for an Automatic Buck-Boost Converter module (like an XL6009 or LM2596-LM2577 combo module) rated for at least 2 Amps.
How it works: It automatically steps the voltage up when the wind is low and steps it down when the wind is high, maintaining a steady 12V output.
Setup: Connect the wires from your pump to the IN+ and IN- terminals, use a multimeter on the OUT terminals, and turn the small potentiometer screw on the module until the output reads exactly 12V.
2. Add a Blocking Diode (Essential for Battery/Load Protection)
If you connect your dynamo directly to a battery or a smart device without a diode, two problems happen:
When the wind stops, the battery will feed power back into the motor, causing it to spin like a fan and drain your battery.
Solution: Place a standard diode (like a 1N5408 or a Schottky diode for higher efficiency) on the positive wire between the pump and the converter, with the silver stripe facing toward the converter.
3. Use a 12V Battery for True "Constant" Power
Even with a buck-boost converter, if the wind drops completely, the power cuts out. To get true, reliable 12V power, you should introduce a small storage buffer:
The Flow: Dynamo \rightarrow Diode \rightarrow Buck-Boost Converter (set to ~13.8V for charging) \rightarrow 12V Lead-Acid or LiFePO4 Battery \rightarrow Your 12V Load.
This ensures your devices run smoothly even during brief lulls in the wind.
Summary Wiring Guide
[ Pump / Dynamo ] ---> [ Diode (A ->|-- K) ] ---> [ Buck-Boost Converter ] ---> [ 12V Battery / Load ]
Using your wind-powered dynamo to run a 12V light and fan is a fantastic, practical application!
Because a fan (which has its own motor) and lights require a steady, uninterrupted flow of current to run smoothly without flickering or stalling, incorporating a small 12V rechargeable battery into your system is highly recommended. The wind will charge the battery, and the battery will provide stable, reliable power to your light and fan.
Here is the step-by-step setup to make this work safely and efficiently:
1. The Wiring Layout
To connect everything safely, follow this layout. The battery acts as a "buffer" so your light and fan don't turn off every time the wind slows down.
Dynamo to Diode: Connect the positive (red) wire of your booster pump dynamo to the positive input of your converter. Put a blocking diode (like a 1N5408) in line on this wire (with the silver stripe pointing away from the pump) to prevent the battery from spinning the pump when the wind stops.
Diode to Buck-Boost Converter: Connect the wires to the IN+ and IN- terminals of your DC-to-DC Buck-Boost converter.
Adjust the Voltage: Before connecting your battery, spin your wind turbine (or use a drill on the shaft to spin it), test the OUT terminals of the converter with a multimeter, and adjust the converter's dial until it outputs exactly 13.8V to 14.2V (the standard charging voltage for a 12V lead-acid battery).
Converter to Battery: Connect the OUT+ and OUT- of the converter to the corresponding terminals of a 12V Lead-Acid battery (like a motorcycle or UPS battery).
Battery to Light and Fan: Connect your 12V DC light and 12V DC fan directly to the battery terminals, ideally through a simple on/off switch.
2. Sizing Your Components
To make sure your system runs smoothly without overheating, keep these electrical limits in mind:
The Fan & Light Power: Your booster pump dynamo can realistically generate about 10 to 15 Watts of continuous power in good wind (roughly 0.8\text{ A} to 1.0\text{ A} at 12\text{V}).
Choosing the Light: Use highly efficient 12V LED bulbs (usually 3W to 5W). They draw very little current and will run for hours.
Choosing the Fan: A small 12V DC brushless fan (like a car cooling fan, a cabin fan, or a high-velocity 12V PC fan) typically draws around 3W to 6W.
Battery Size: A small 12V 7Ah (Amp-hour) battery (commonly used in home UPS systems or emergency lights) is perfect for this. It is affordable, easy to charge with your pump, and can run a 5W light and 5W fan together for about 6 to 8 hours on a full charge even if there is absolutely no wind.
3. Quick Safety Tip
Always place a simple 3-Amp or 5-Amp fuse on the wire coming out of the battery's positive terminal before it goes to your light and fan. This protects your wiring and components in case there is ever a short circuit.
How do you plan to mount the blades to the pump's shaft? If you need ideas for a simple pulley or hub connection, let me know!
